| Aircraft |
|---|
| Takeoff Weight |
< 249 g
Standard aircraft weight (incl. Intelligent Flight Battery, propellers, microSD). Actual weight may vary by batch/materials/external factors. With Intelligent Flight Battery Plus*, weight > 249 g. Always check local laws.
|
| Dimensions |
Folded (w/o props): 148 × 94 × 64 mm (L × W × H)
Unfolded (with props): 298 × 373 × 101 mm (L × W × H) |
| Max Ascent Speed |
5 m/s (S), 5 m/s (N), 3 m/s (C) |
| Max Descent Speed |
5 m/s (S), 5 m/s (N), 3 m/s (C) |
| Max Horizontal Speed* |
16 m/s (S), 12 m/s (N), 12 m/s (C) at sea level, no wind
*Subject to dynamic local restrictions. Obey local laws.
|
| Max Takeoff Altitude |
4000 m (with Mini 4 Pro Intelligent Flight Battery)
3000 m (with Mini 3 Series Intelligent Flight Battery Plus*)
*Battery Plus not sold in Europe. Added weight reduces propulsion; avoid extra payloads.
|
| Max Flight Time |
34 min (Intelligent Flight Battery)
45 min (Intelligent Flight Battery Plus*)
Measured at 21.6 km/h, no wind, 20 m ASL, photo mode, Obstacle Action Off, from 100% to 0%.
|
| Max Hovering Time |
30 min (Intelligent Flight Battery)
39 min (Intelligent Flight Battery Plus*) |
| Max Flight Distance |
18 km (Intelligent Flight Battery @ 40.7 km/h)
25 km (Intelligent Flight Battery Plus* @ 44.3 km/h) |
| Max Wind Resistance |
10.7 m/s |
| Max Pitch Angle |
35° |
| Operating Temperature |
-10° to 40° C (14° to 104° F) |
| GNSS |
GPS + Galileo + BeiDou |
| Hovering Accuracy (no/low wind) |
Vertical: ±0.1 m (vision), ±0.5 m (GNSS)
Horizontal: ±0.1 m (vision), ±0.5 m (GNSS) |
| Internal Storage |
2 GB |
| Class |
C0 (EU), optional C1 (EU) via DJI Fly app |
| Camera |
|---|
| Image Sensor |
1/1.3" CMOS, Effective 48 MP |
| Lens |
FOV 82.1°, 24 mm equiv., f/1.7, Focus 1 m to ∞ |
| ISO Range (Video) |
Normal/Slow Mo: 100–6400 (Normal), 100–1600 (D-Log M), 100–1600 (HLG)
Night: 100–12800 (Normal) |
| ISO Range (Photo) |
12 MP: 100–6400; 48 MP: 100–3200 |
| Shutter Speed |
12 MP: 1/16000–2 s (2.5–8 s simulated long exposure)
48 MP: 1/8000–2 s |
| Max Image Size |
8064 × 6048 |
| Still Modes |
Single (12/48 MP); Burst: 12 MP (3/5/7), 48 MP (3/5); AEB: 12 MP (3/5/7 @ 0.7 EV), 48 MP (3/5 @ 0.7 EV); Timed: 12 MP (2–60 s), 48 MP (5–60 s) |
| Photo Format |
JPEG / DNG (RAW) |
| Video Resolution / Rates |
4K: 3840×2160 @ 24/25/30/48/50/60/100* fps
FHD: 1920×1080 @ 24/25/30/48/50/60/100*/200* fps
*100/200 fps recorded as slow motion. 4K/100 and HLG/D-Log M require H.265.
|
| Codec / Container |
H.264/H.265 (MP4) |
| Max Video Bitrate |
150 Mbps (H.264/H.265) |
| File System |
exFAT |
| Color & Sampling |
Normal: 8-bit 4:2:0 (H.264/H.265); HLG/D-Log M: 10-bit 4:2:0 (H.265) |
| Digital Zoom |
Photo 12 MP: 1–3×; 4K: 1–3×; FHD: 1–4× |
| Gimbal |
|---|
| Type |
3-axis mechanical (tilt/roll/pan) |
| Mechanical Range |
Tilt −135° to 80°; Roll −135° to 45°; Pan −30° to 30° |
| Controllable Range |
Tilt −90° to 60°; Roll −90° or 0° |
| Max Tilt Control Speed |
100°/s |
| Angular Vibration |
±0.01° |
| Sensing |
|---|
| Type |
Omnidirectional binocular vision + 3D IR bottom sensor |
| Forward |
Measure 0.5–18 m; Detect 0.5–200 m; ≤ 12 m/s; FOV H90°/V72° |
| Backward |
Measure 0.5–15 m; ≤ 12 m/s; FOV H90°/V72° |
| Lateral |
Measure 0.5–12 m; ≤ 12 m/s; FOV H90°/V72° |
| Upward |
Measure 0.5–15 m; ≤ 5 m/s; FOV Front/Back 72°, Left/Right 90° |
| Downward |
Measure 0.3–12 m; ≤ 5 m/s; FOV Front/Back 106°, Left/Right 90° |
| Operating Environment |
All directions: textured surfaces, lux > 15. Downward: textured surfaces, diffuse reflectivity > 20% (e.g., walls/trees/people), lux > 15. |
| 3D Infrared |
Range 0.1–8 m (reflectivity > 10%), FOV Front/Back 60°, Left/Right 60° |
| Video Transmission (O4) |
|---|
| Live View Quality |
RC: up to 1080p/60 (Photo/Video flight), up to 1080p/30 (Video flight), up to 1080p/24 (ground standby) |
| Frequencies |
2.4000–2.4835 GHz; 5.170–5.250 GHz; 5.725–5.850 GHz
5.170–5.250 GHz only where permitted.
|
| EIRP |
2.4 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (CE)
5.8 GHz: < 33 dBm (FCC), < 30 dBm (SRRC), < 14 dBm (CE) |
| Max Transmission Distance* |
FCC 20 km; CE/SRRC/MIC 10 km
*Unobstructed, interference-free; one-way non-return. Follow RTH prompts in DJI Fly.
|
| With Interference (unobstructed) |
Strong (urban): ~1.5–4 km; Medium (suburban): ~4–10 km; Low (suburb/seaside): ~10–20 km (FCC) |
| Obstructed, Low Interference |
Buildings: ~0–0.5 km; Trees: ~0.5–3 km (FCC) |
| Max Download Speed |
O4: 10 MB/s (DJI RC-N2), 10 MB/s (DJI RC 2); Wi-Fi 5: 30 MB/s* |
| Lowest Latency |
~120 ms (aircraft + RC; environment/device dependent) |
| Antenna |
4 antennas, 2T4R |
| Battery |
|---|
| Compatibility |
DJI Mini 4 Pro Intelligent Flight Battery; DJI Mini 3 Series Intelligent Flight Battery Plus* |
| Capacity |
2590 mAh (Intelligent Flight Battery); 3850 mAh (Battery Plus*) |
| Weight |
~77.9 g (Battery); ~121 g (Battery Plus*) |
| Nominal Voltage |
7.32 V (Battery); 7.38 V (Battery Plus*) |
| Max Charging Voltage |
8.6 V (Battery); 8.5 V (Battery Plus*) |
| Type / Energy |
Li-ion; 18.96 Wh (Battery); 28.4 Wh (Battery Plus*) |
| Charging Temp. |
5° to 40° C (41° to 104° F) |
| Charging Time |
Battery: 70 min (DJI 30W PD, in aircraft); 58 min (30W PD, Two-Way Hub)
Battery Plus*: 101 min (30W PD, in aircraft); 78 min (30W PD, Two-Way Hub) |
| Charger |
|---|
| Recommended |
DJI 30W USB-C Charger or other 30 W USB Power Delivery chargers
Max charging power (aircraft or Two-Way Hub): 30 W.
|
| Two-Way Charging Hub |
|---|
| Input |
5 V 3 A; 9 V 3 A; 12 V 3 A |
| Output |
USB-A: 5 V / 2 A (max) |
| Charging Type |
Three batteries charged in sequence |
| Compatibility |
Mini 4 Pro Intelligent Flight Battery; Mini 3 Series Intelligent Flight Battery/Plus* |
| Storage |
|---|
| Recommended microSD |
SanDisk Extreme PRO 32GB V30 U3 A1 microSDHC;
Lexar 1066x 64/128/256/512GB V30 U3 A2 microSDXC;
Kingston Canvas GO! Plus 64/128GB V30 U3 A2 microSDXC;
Kingston Canvas React Plus 64/128/256GB V90 U3 A1 microSDXC;
Samsung EVO Plus 512GB V30 U3 A2 microSDXC
|
| Remote Controller — DJI RC-N2 |
|---|
| Max Operating Time |
6 h (no phone charging); 3.5 h (charging phone) |
| Supported Phone Size |
180 × 86 × 10 mm (L × W × H) |
| Operating / Charging Temp. |
-10° to 40° C / 5° to 40° C |
| Charging Time |
≈ 2.5 h (use 5V/2A charger) |
| Battery |
18.72 Wh (3.6 V, 2600 mAh ×2) |
| Device Ports |
Lightning, USB-C, Micro-USB*
*Micro-USB cable (RC-N1 Standard Micro USB) sold separately.
|
| Tx Frequencies |
2.4000–2.4835 GHz; 5.170–5.250 GHz; 5.725–5.850 GHz |
| EIRP |
2.4 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (CE)
5.8 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 30 dBm (SRRC) |
| Other |
|---|
| Guaranteed Software Updates |
Until 2026/12/31 |
* The Intelligent Flight Battery Plus is not sold in Europe. Specifications that mention the Plus battery apply only where available.
All ranges, times, and distances are tested in controlled environments and may vary by conditions, firmware, and regulations.
